1969 Chevrolet Camaro
Price: $0.00
Ad Number: #21922
SELLER INFORMATION
Listed By:
GoodGuysAdsRJ
Seller Number:
Show Seller Phone
(612) 845-2515
Posted:
Apr 18
Location:
ANDOVER, MN
CAR SPECIFICATIONS
Price:
$0.00
Year:
1969
Make/Model:
Chevrolet Camaro
Drive Type:
-
Mileage:
-
Doors:
-
Body Type:
Coupe
Transmission:
-
Fuel Type:
-
Engine:
-
Exterior Color:
-
Vin:
Description:
The intention for this build, 1969 Camaro Pro Touring.
This car build was engineered and built to the current point by Gizmos LLC. The intention was to build a high horse power, Pro Touring 1969 Camaro that will function to the highest level. In addition to the functionality, the ascetics were intended to compete at the most admired car shows.
The engineered integrated 4130 chrome molly role cage built into the car and a-piller, is a signature of the car builder and a must see. This car is also outfitted with a custom, hand-built, three-link rear suspension that includes the billet Watts-Link. The front suspension is based on a C6 corvette IFS. This combination gives this car both street drivability and the edge on the race track.
The power plant consists of a very hardy built Big Block Chevy based engine. All of the components are above and beyond. From bottom to top and everything in-between, starting with a Daily’s billet drysump oil pan/pump system all the way to the top where a one-off billet intake was engineered machined.
Twin turbos are tucked in and out of sight in the front fenders. Giving this build a very clean, curious, and un assuming look. The Turbos are capable of big power but are also able to be de-tuned for easy street driving.
With big power takes big brakes! As with all the components for the build, the BEST brakes in the world were sourced, engineered, and used for this build. Brembo GTS Billet nickel plated calipers and missive rotors are a show stopper and must see in themselves. 18” & 20” custom Schott wheels with Michelin Pilot tires are the shoes that fit the look aswell as provide the grip.
The body is a new Dynacorn 1969 Camaro body. It includes the doors, cowl hood, trunk lid and RS grill. The doors and fenders have been fitted and gapped.
This is a great start to a very high-end build.
The build is attached to a chassis table and is part of the sale.
• Chassis and Suspension
o Art Morrison GT Sport Chassis
o C6 Front IFS Platform
o DSE 20:1 Power Steering Rack
o Set up for Penskie Double adjustable front shocks
o Strange 9” axle housing with Gizmos bracketry and reinforcement supports
o Strange HD Aluminum S-Track differential 3:70 gear
o Strange 36 Spline axles
o Gizmos billet Watts link with fabricated links and bracketry
o Gizmos custom three link rear suspension
o FK rod ends
o Gizmos rear anti-roll bar components
o Set up for Penskie double adjustable coil over shocks
• Engine
o Turbo boosted engine Built by Wheeler Racing Engines
o Built capable up to 2000 Horse Power with ability to detune
o E85 / Flex Fuel Engine
o 540 c.i. 8.8 to 1 compression
o Dart Big M Sportsman Block
o Callies Crank
o Manley H-Beam Rods
o JE Turbo/Blower Pistons
o Brodix BB 3 Heads, Outsides Polished
o Aluminum Sheet metal Valve Covers, Polished
o Daily Billet 7-Stage Dry Sump oil pan/oil pump system
o Nth Moto Billet engineered and machined intake
o CSR high torque Starter
• Turbo System
o 76mm Garrett Turbos with Tial Compact Housing
o Air to Liquid Intercooler Cores
o Turbosmart 45 Wastegates
o Turbosmart Raceport BOV’s
• Engine Accessories
o Jones Racing Products drive accessories
o AC Compressor, PS, Alternator,
• Transmission
o Chassis built for a GM 4l80E
o Empty mock-up transmission housing fitted to build
• Body
o 1969 New Dynacorn Body
o R/S Camaro Trim Package
o Steel hood with 2” Cowl
o EMS Billet Hood Hinges
o Serial no CA69CP160101TW
o Includes VIN Number
• Wheels and Tires
o Schott, Americana, Front Wheels 18x12
o Schott, Americana, Rear Wheels 20x12
o Michelin Pilot SS XL 255/35/ZR18 Front
o Michelin Pilot SS XL 315/35ZR20 Rear
• Brakes
o Brembo GTR Billet / Nicle Plated 6 Piston Calipers Front
o Brembo GTR Billet / Nicle Plated 4 Piston Calipers Rear
o 14” Brembo Rotors Front
o 15” Brembo Rotors Rear
• Fuel System
o ATL Fuel Cell, 22 Gallon
